KET SS CANNULATED FEMUR NAILING SYSTEM
Anatomical Implants
KET SS Cannulated Femur Nailing System has an advanced anatomical design designed to suit small statured population.
CFN2 allows easy insertion and extraction of this nail.
Flattened lateral side reduces impingement of the lateral cortex and decreases medialisation.
It has multiple locking options:
Multiple locking options (Proximal):
- Standard locking – Femoral shaft fractures (except subtrochanteric fractures)
- Recon locking – Subtrochanteric fractures – Combined femoral shaft and neck fractures (ipsilateral)
Multiple Locking options (Distal):
- High stability through multiplanar screws
- Antirotational stability
- Distal dynamisation option
Size Chart
Available Anatomically in:
Diameters: 9mm, 10mm, 11mm and 12mm.
Lengths: 340mm to 460mm.
Indication
For Standard Locking Indications:
- CFN2 with standard locking is indicated for fractures in the femoral shaft (except subtrochanteric fractures)
Recon Locking Indications:
- CFN2 with recon locking is indicated for fractures in the femoral shaft in case of combination with femoral neck fractures
- Additionally CFN2 is indicated for fractures in the subtrochanteric section combined with shaft femoral fracture.
Size Chart
| Part No. | Description | Size | |
|---|---|---|---|
| Hole /Diameter. | Length | ||
| MT-NS1809340L | 9.0mm SS Cannulated Femur Nail Left 340mm Length | 9.0 | 340 |
| MT-NS1810340L | 10.0mm SS Cannulated Femur Nail Left 340mm Length | 10.0 | 340 |
| MT-NS1811340L | 11.0mm SS Cannulated Femur Nail Left 340mm Length | 11.0 | 340 |
| MT-NS1812340L | 12.0mm SS Cannulated Femur Nail Left 340mm Length | 12.0 | 340 |
| MT-NS1809360L | 9.0mm SS Cannulated Femur Nail Left 360mm Length | 9.0 | 360 |
| MT-NS1810360L | 10.0mm SS Cannulated Femur Nail Left 360mm Length | 10.0 | 360 |
| MT-NS1811360L | 11.0mm SS Cannulated Femur Nail Left 360mm Length | 11.0 | 360 |
| MT-NS1812360L | 12.0mm SS Cannulated Femur Nail Left 360mm Length | 12.0 | 360 |
| MT-NS1809380L | 9.0mm SS Cannulated Femur Nail Left 380mm Length | 9.0 | 380 |
| MT-NS1810380L | 10.0mm SS Cannulated Femur Nail Left 380mm Length | 10.0 | 380 |
| MT-NS1811380L | 11.0mm SS Cannulated Femur Nail Left 380mm Length | 11.0 | 380 |
| MT-NS1812380L | 12.0mm SS Cannulated Femur Nail Left 380mm Length | 12.0 | 380 |
| MT-NS1809400L | 9.0mm SS Cannulated Femur Nail Left 400mm Length | 9.0 | 400 |
| MT-NS1810400L | 10.0mm SS Cannulated Femur Nail Left 400mm Length | 10.0 | 400 |
| MT-NS1811400L | 11.0mm SS Cannulated Femur Nail Left 400mm Length | 11.0 | 400 |
| MT-NS1812400L | 12.0mm SS Cannulated Femur Nail Left 400mm Length | 12.0 | 400 |
| MT-NS1809420L | 9.0mm SS Cannulated Femur Nail Left 420mm Length | 9.0 | 420 |
| MT-NS1810420L | 10.0mm SS Cannulated Femur Nail Left 420mm Length | 10.0 | 420 |
| MT-NS1811420L | 11.0mm SS Cannulated Femur Nail Left 420mm Length | 11.0 | 420 |
| MT-NS1812420L | 12.0mm SS Cannulated Femur Nail Left 420mm Length | 12.0 | 420 |
| MT-NS1809440L | 9.0mm SS Cannulated Femur Nail Left 440mm Length | 9.0 | 440 |
| MT-NS1810440L | 10.0mm SS Cannulated Femur Nail Left 440mm Length | 10.0 | 440 |
| MT-NS1811440L | 11.0mm SS Cannulated Femur Nail Left 440mm Length | 11.0 | 440 |
| MT-NS1812440L | 12.0mm SS Cannulated Femur Nail Left 440mm Length | 12.0 | 440 |
| MT-NS1809460L | 9.0mm SS Cannulated Femur Nail Left 460mm Length | 9.0 | 460 |
| MT-NS1810460L | 10.0mm SS Cannulated Femur Nail Left 460mm Length | 10.0 | 460 |
| MT-NS1811460L | 11.0mm SS Cannulated Femur Nail Left 460mm Length | 11.0 | 460 |
| MT-NS1812460L | 12.0mm SS Cannulated Femur Nail Left 460mm Length | 12.0 | 460 |
| MT-NS1809340R | 9.0mm SS Cannulated Femur Nail Right 340mm Length | 9.0 | 340 |
| MT-NS1810340R | 10.0mm SS Cannulated Femur Nail Right 340mm Length | 10.0 | 340 |
| MT-NS1811340R | 11.0mm SS Cannulated Femur Nail Right 340mm Length | 11.0 | 340 |
| MT-NS1812340R | 12.0mm SS Cannulated Femur Nail Right 340mm Length | 12.0 | 340 |
| MT-NS1809360R | 9.0mm SS Cannulated Femur Nail Right 360mm Length | 9.0 | 360 |
| MT-NS1810360R | 10.0mm SS Cannulated Femur Nail Right 360mm Length | 10.0 | 360 |
| MT-NS1811360R | 11.0mm SS Cannulated Femur Nail Right 360mm Length | 11.0 | 360 |
| MT-NS1812360R | 12.0mm SS Cannulated Femur Nail Right 360mm Length | 12.0 | 360 |
| MT-NS1809380R | 9.0mm SS Cannulated Femur Nail Right 380mm Length | 9.0 | 380 |
| MT-NS1810380R | 10.0mm SS Cannulated Femur Nail Right 380mm Length | 10.0 | 380 |
| MT-NS1811380R | 11.0mm SS Cannulated Femur Nail Right 380mm Length | 11.0 | 380 |
| MT-NS1812380R | 12.0mm SS Cannulated Femur Nail Right 380mm Length | 12.0 | 380 |
| MT-NS1809400R | 9.0mm SS Cannulated Femur Nail Right 400mm Length | 9.0 | 400 |
| MT-NS1810400R | 10.0mm SS Cannulated Femur Nail Right 400mm Length | 10.0 | 400 |
| MT-NS1811400R | 11.0mm SS Cannulated Femur Nail Right 400mm Length | 11.0 | 400 |
| MT-NS1812400R | 12.0mm SS Cannulated Femur Nail Right 400mm Length | 12.0 | 400 |
| MT-NS1809420R | 9.0mm SS Cannulated Femur Nail Right 420mm Length | 9.0 | 420 |
| MT-NS1810420R | 10.0mm SS Cannulated Femur Nail Right 420mm Length | 10.0 | 420 |
| MT-NS1811420R | 11.0mm SS Cannulated Femur Nail Right 420mm Length | 11.0 | 420 |
| MT-NS1812420R | 12.0mm SS Cannulated Femur Nail Right 420mm Length | 12.0 | 420 |
| MT-NS1809440R | 9.0mm SS Cannulated Femur Nail Right 440mm Length | 9.0 | 440 |
| MT-NS1810440R | 10.0mm SS Cannulated Femur Nail Right 440mm Length | 10.0 | 440 |
| MT-NS1811440R | 11.0mm SS Cannulated Femur Nail Right 440mm Length | 11.0 | 440 |
| MT-NS1812440R | 12.0mm SS Cannulated Femur Nail Right 440mm Length | 12.0 | 440 |
| MT-NS1809460R | 9.0mm SS Cannulated Femur Nail Right 460mm Length | 9.0 | 460 |
| MT-NS1810460R | 10.0mm SS Cannulated Femur Nail Right 460mm Length | 10.0 | 460 |
| MT-NS1811460R | 11.0mm SS Cannulated Femur Nail Right 460mm Length | 11.0 | 460 |
| MT-NS1812460R | 12.0mm SS Cannulated Femur Nail Right 460mm Length | 12.0 | 460 |
| MT-SS2649022 | 4.9mm Locking Bolt Self Tapping (SS) 22mm Length | 4.9 | 22 |
| MT-SS2649024 | 4.9mm Locking Bolt Self Tapping (SS) 24mm Length | 4.9 | 24 |
| MT-SS2649026 | 4.9mm Locking Bolt Self Tapping (SS) 26mm Length | 4.9 | 26 |
| MT-SS2649028 | 4.9mm Locking Bolt Self Tapping (SS) 28mm Length | 4.9 | 28 |
| MT-SS2649030 | 4.9mm Locking Bolt Self Tapping (SS) 30mm Length | 4.9 | 30 |
| MT-SS2649032 | 4.9mm Locking Bolt Self Tapping (SS) 32mm Length | 4.9 | 32 |
| MT-SS2649034 | 4.9mm Locking Bolt Self Tapping (SS) 34mm Length | 4.9 | 34 |
| MT-SS2649036 | 4.9mm Locking Bolt Self Tapping (SS) 36mm Length | 4.9 | 36 |
| MT-SS2649038 | 4.9mm Locking Bolt Self Tapping (SS) 38mm Length | 4.9 | 38 |
| MT-SS2649040 | 4.9mm Locking Bolt Self Tapping (SS) 40mm Length | 4.9 | 40 |
| MT-SS2649042 | 4.9mm Locking Bolt Self Tapping (SS) 42mm Length | 4.9 | 42 |
| MT-SS2649044 | 4.9mm Locking Bolt Self Tapping (SS) 44mm Length | 4.9 | 44 |
| MT-SS2649046 | 4.9mm Locking Bolt Self Tapping (SS) 46mm Length | 4.9 | 46 |
| MT-SS2649048 | 4.9mm Locking Bolt Self Tapping (SS) 48mm Length | 4.9 | 48 |
| MT-SS2649050 | 4.9mm Locking Bolt Self Tapping (SS) 50mm Length | 4.9 | 50 |
| MT-SS2649052 | 4.9mm Locking Bolt Self Tapping (SS) 52mm Length | 4.9 | 52 |
| MT-SS2649054 | 4.9mm Locking Bolt Self Tapping (SS) 54mm Length | 4.9 | 54 |
| MT-SS2649056 | 4.9mm Locking Bolt Self Tapping (SS) 56mm Length | 4.9 | 56 |
| MT-SS2649058 | 4.9mm Locking Bolt Self Tapping (SS) 58mm Length | 4.9 | 58 |
| MT-SS2649060 | 4.9mm Locking Bolt Self Tapping (SS) 60mm Length | 4.9 | 60 |
| MT-SS2649062 | 4.9mm Locking Bolt Self Tapping (SS) 62mm Length | 4.9 | 62 |
| MT-SS2649064 | 4.9mm Locking Bolt Self Tapping (SS) 64mm Length | 4.9 | 64 |
| MT-SS2649066 | 4.9mm Locking Bolt Self Tapping (SS) 66mm Length | 4.9 | 66 |
| MT-SS2649068 | 4.9mm Locking Bolt Self Tapping (SS) 68mm Length | 4.9 | 68 |
| MT-SS2649070 | 4.9mm Locking Bolt Self Tapping (SS) 70mm Length | 4.9 | 70 |
| MT-SS2649072 | 4.9mm Locking Bolt Self Tapping (SS) 72mm Length | 4.9 | 72 |
| MT-SS2649074 | 4.9mm Locking Bolt Self Tapping (SS) 74mm Length | 4.9 | 74 |
| MT-SS2649076 | 4.9mm Locking Bolt Self Tapping (SS) 76mm Length | 4.9 | 76 |
| MT-SS2649078 | 4.9mm Locking Bolt Self Tapping (SS) 78mm Length | 4.9 | 78 |
| MT-SS2649080 | 4.9mm Locking Bolt Self Tapping (SS) 80mm Length | 4.9 | 80 |
| MT-SS8064050 | 6.4mm Cannulated Bolt Self Tapping (SS) 50mm Length | 6.4 | 50 |
| MT-SS8064055 | 6.4mm Cannulated Bolt Self Tapping (SS) 55mm Length | 6.4 | 55 |
| MT-SS8064060 | 6.4mm Cannulated Bolt Self Tapping (SS) 60mm Length | 6.4 | 60 |
| MT-SS8064065 | 6.4mm Cannulated Bolt Self Tapping (SS) 65mm Length | 6.4 | 65 |
| MT-SS8064070 | 6.4mm Cannulated Bolt Self Tapping (SS) 70mm Length | 6.4 | 70 |
| MT-SS8064075 | 6.4mm Cannulated Bolt Self Tapping (SS) 75mm Length | 6.4 | 75 |
| MT-SS8064080 | 6.4mm Cannulated Bolt Self Tapping (SS) 80mm Length | 6.4 | 80 |
| MT-SS8064085 | 6.4mm Cannulated Bolt Self Tapping (SS) 85mm Length | 6.4 | 85 |
| MT-SS8064090 | 6.4mm Cannulated Bolt Self Tapping (SS) 90mm Length | 6.4 | 90 |
| MT-SS8064095 | 6.4mm Cannulated Bolt Self Tapping (SS) 95mm Length | 6.4 | 95 |
| MT-SS8064100 | 6.4mm Cannulated Bolt Self Tapping (SS) 100mm Length | 6.4 | 100 |
| MT-SS8064105 | 6.4mm Cannulated Bolt Self Tapping (SS) 105mm Length | 6.4 | 105 |
| MT-SS8064110 | 6.4mm Cannulated Bolt Self Tapping (SS) 110mm Length | 6.4 | 110 |
| MT-SS8064115 | 6.4mm Cannulated Bolt Self Tapping (SS) 115mm Length | 6.4 | 115 |
Clinical Data
Product IFU
Note: IFU will be displayed after MDR Certification
