Product Overview

Brochure

MOZEC^TM NC PTCA Balloon Dilatation Catheter is indicated for balloon dilatation of the stenotic portion of a coronary artery or a bypass graft stenosis for the purpose of improving myocardial perfusion and also for post-delivery expansion of balloon expandable stents.
US-FDA approved and also available in China, Japan, Canada, Australia, Korea, Latin America, Asia, Middle-East & Africa.
Low 0.019” distal tip entry profile ensures navigation post stent deployment.
Small abrupt balloon shoulders help avoid injury to healthy vessel adjacent to the lesion.
MeriStem^TM hypo-tube shaft for enhanced support and pushability with MeriGlide^TM hydrophilic coating on distal shaft for smooth trackability.
Swaged low profile RO marker band for accurate visibility.
5 Fr Guide catheter compatible and 6F compatibility for kissing balloon.

Non-Compliant Balloon material for controlled growth.

Best in class trackability and pushability for ease of navigation.

Quick Inflation & Deflation.

USFDA approved.

Catheter Design	Rapid Exchange
Tip Entry Profile	0.019”
Crossing Profile	0.70-1.40 mm
Balloon material composition	Nylon (Non-Compliant)
Balloon Compliance	Non-Compliant
Hydrophilic Coating	MeriGlide^TM - from base of distal tip to Rx-port
Nominal	12atm
RBP	20atm

DIA/Length	8 mm	12 mm	13 mm	15 mm	18 mm	23 mm	28 mm	30 mm	35 mm	38 mm
2.00 mm	MNC20008	MNC20012	MNC20013	MNC20015	MNC20018	MNC23023	MNC20028	MNC20030	MNC20035	MNC20038
2.25 mm	MNC22508	MNC22512	MNC22513	MNC22515	MNC22518	MNC22523	MNC22828	MNC22530	MNC22535	MNC22538
2.50 mm	MNC25008	MNC25012	MNC25013	MNC25015	MNC25018	MNC25023	MNC28028	MNC25030	MNC25035	MNC25038
2.75 mm	MNC27508	MNC27512	MNC27513	MNC27515	MNC27518	MNC27523	MNC27528	MNC27530	MNC27535	MNC27538
3.00 mm	MNC30008	MNC30012	MNC30013	MNC30015	MNC30018	MNC30023	MNC30028	MNC30030	MNC30035	MNC30038
3.25 mm	MNC32508	MNC32512	MNC32513	MNC32515	MNC32518	MNC32523	MNC32828	MNC32530	MNC32535	MNC32538
3.50 mm	MNC35008	MNC35012	MNC35013	MNC35015	MNC35018	MNC35023	MNC35028	MNC35030	MNC35035	MNC35038
4.00 mm	MNC40008	MNC40012	MNC40013	MNC40015	MNC40018	MNC40023	MNC40028	MNC40030	MNC40035	MNC40038
4.50 mm	MNC45008	MNC45012	MNC45013	MNC45015	MNC45018	MNC45023	MNC45028	MNC45030	MNC45035	MNC45038
5.00 mm	MNC50008	MNC50012	MNC50013	MNC50015	MNC50018	MNC50023	MNC50028	MNC50030	-	-

Contact your country local Meril sales representative for availibility of sizes highlighted in blue

Note: IFU will be displayed after MDR Certification
